Growatt

PV Smart Meter GROWATT TPMCTE100A, 100A

Name: PV Smart Meter GROWATT TPMCTE100A, 100A
Brand: Growatt
SKU: NV820351
Price: 199.65 EUR
Availability: InStock

€199,65

VAT included. Shipping calculated at checkout.

SKU: NV820351 · EAN: 6975609727242

In stock — ships in 1–2 business days

Free EU shipping over €49
24-month warranty included
14-day hassle-free returns

PV smart meter 100A, 3-phase, with RS485, Modbus, 3P4WFeatures:The smart meter is designed for grid export limitation and self-consumption monitoring.Compatible with Growatt PV inverters.Class1 measurement reliability.With LCD display.Smart Meter is easy to mount on Din rail.
Specifications: Rated voltage: AC 230/400V.L-L voltage range: AC 173 ~ 480V.L-N voltage range: AC 100 ~ 289V.Current: 100A.Frequency: 50/60Hz.Number of phases: 3.Accuracy class: class 1 (voltage/current 0.5%, power 1%, frequency 0.2%).Interface: RS485.Baud rate 9600 bit/s.Communication protocol: Modbus RTU.Installation: on DIN rail 35mm.Dimensions: 95.5x72x65 mm.Safety class: IP51.Operating temperature: -25°C to 55°C.Operating humidity: 0-90% non-condensing.Weight: 280g.Colour: white.Certifications: CE.Consumption: 2W.RS485 cable length: 15m.
Warranty: 24 months.
Download Quick Guide TPMCTE.pdf
