Growatt

PV Smart Meter GROWATT SPM-C, 1-phase, 5A~60A

Name: PV Smart Meter GROWATT SPM-C, 1-phase, 5A~60A
Brand: Growatt
SKU: NV821136
Price: 98.19 EUR
Availability: InStock

€98,19

VAT included. Shipping calculated at checkout.

SKU: NV821136 · EAN: 9990000821136

In stock — ships in 1–2 business days

Free EU shipping over €49
24-month warranty included
14-day hassle-free returns

PV smart meter 5-60A, 1-phase, with RS485, Modbus, 1P2WFeatures:The smart meter is designed for grid export limitation and self-consumption monitoring.Compatible with Growatt PV inverters.Class1 measurement reliability.With LCD display.Smart Meter is easy to mount on Din rail.
Specifications: Rated voltage: AC 230/400V.L-N voltage range: AC 184V ~ 276V.Current: 5A.Current range: 5A ~ 60A.Frequency: 50/60Hz.Number of phases: 1.Accuracy class: class 1 (voltage/current 0.5%, power 1%, frequency 0.2%).Interface: RS485.Baud rate 9600 bit/s.Communication protocol: Modbus RTU.Installation: on DIN rail.Dimensions: 99x63x36 mm.Safety class: IP51.Operating temperature: -25°C to 55°C.Operating humidity: <75%RH.Weight: 223g.Colour: white.Certifications: CE, RoHS.Consumption: <2W / 10VA.RS485 cable length: 15m.
Warranty: 24 months.Download Specifications SPM-TPM.pdf
